| Model |
FLA48500 |
| Battery Type |
LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Voltage |
51.2V (48V system nominal) |
| Operating Voltage Range |
44.8V – 57.6V |
| Capacity |
500Ah |
| Energy Capacity |
25–25.6kWh (nominal; ~20–24kWh usable at 80–95% DoD) |
| Depth of Discharge (DoD) |
≥80–95% (recommended) |
| Cycle Life |
≥6000 cycles @ 80–95% DoD (at 25°C) |
| Max Charge/Discharge Current |
≤200A (continuous; up to 300A@15s peak) |
| Max Charge/Discharge Power |
≤10,000W (recommended; peak up to 15,000W@15s) |
| Communication |
RS485 / CAN (WiFi optional in variants) |
| Scalability |
Up to 15 units in parallel (~375kWh total) |
| Installation |
Wall-mounted or floor-mounted |
| Protection Level |
IP21 (indoor/general; use enclosure for outdoor/coastal) |
| Operating Temperature |
Charge: 0–55°C; Discharge: -20–55°C (suitable for tropical/coastal) |
| Warranty |
7 years (common in Kenya sellers) |
| Certifications |
UN38.3, others per Felicity |
| Dimensions / Weight |
Approx. 718x380x990mm / 218–248kg (gross) |
