Description
Key Features
- Three-Phase Output: Balanced 230V/400V pure sine wave for heavy, stable loads (pumps, AC units, commercial equipment).
- Hybrid Modes: Solar priority, grid-tie with zero-export, self-consumption, battery backup, and generator integration.
- Dual MPPT Trackers: High efficiency for max PV harvest; supports significant over-paneling (up to ~24kW PV input in series).
- IP65 Waterproof: Fully sealed for outdoor/roof/ground installs—perfect for Kilifi’s salty/humid environment.
- High Charge/Discharge: Up to 240A+ (combined solar + AC), enabling fast battery charging and high-power delivery.
- Smart Monitoring: WiFi cloud/app support for remote control, energy flow, time-of-use optimization, and alerts.
- Generator Port: Programmable for smart load/generator access.
- Protections: Overload, short-circuit, overvoltage, anti-islanding, etc.
- Parallel Support: Yes (multiple units for higher power).
Technical Specifications (from Felicity datasheets and listings)
| Specification | Details |
|---|---|
| Model | IVGM16KLP3G1 |
| Rated Power | 16kW / 17.6kVA |
| Battery Voltage Range | 40–60V DC (48V low-voltage nominal) |
| Max Charge/Discharge Current | 240A / 240A |
| Max Charge/Discharge Power | ~10–12kW (up to rated) |
| Max PV Input Power | 24kW (recommended; supports over-paneling) |
| Max PV Voltage (Voc) | 800V DC |
| MPPT Voltage Range | 120–650V DC (or similar; dual MPPT trackers) |
| Max PV Charge Current | High-efficiency MPPT |
| AC Output Voltage | 230/400V AC (three-phase) |
| Output Waveform | Pure Sine Wave |
| Efficiency | Peak >93–95% |
| Transfer Time | <10–20ms (UPS mode) |
| IP Rating | IP65 (waterproof/dustproof) |
| Operating Temperature | Wide range (suitable for tropical/coastal) |
| Communication | WiFi (cloud/app), RS485/CAN |
| Warranty | Up to 5–10 years (seller-dependent) |
| Certifications | IEC/EN, NRS, VDE equivalents |
