Description
Key Features
- Silent Operation: Fanless or ultra-low-noise design (<30–35 dB typical)—perfect for home use without disturbing sleep or daily activities.
- Hybrid Modes: Solar > battery > grid/generator priority; supports off-grid, grid-tie (self-consumption), and backup (EPS/UPS function with fast switchover <10–20ms).
- MPPT Solar Charging: Wide range (e.g., 80–500V or similar), high efficiency (~98%), supports up to 7–10kW PV input in some configs for over-paneling.
- Pure Sine Wave Output: Stable 220–240V AC for sensitive appliances (fridges, TVs, pumps, lights—no humming or damage).
- Battery Compatibility: 48V systems (lead-acid or lithium like Felicity LiFePO₄); high charge/discharge currents (e.g., 100–190A in series models).
- Monitoring: WiFi/app support for remote status, energy flow, and alerts.
- Protections: Overload, short-circuit, overvoltage, anti-islanding, etc.
- Other: Compact design, easy install, generator compatible.
Technical Specifications
| Specification | Details |
|---|---|
| Rated Power | 5kW / 5000W (continuous) |
| Surge/Peak Power | Up to 10kW (short bursts) |
| Battery Voltage | 48V DC nominal (wide range e.g., 40–60V) |
| Output Voltage / Waveform | 220–240V AC Pure Sine Wave |
| Output Frequency | 50/60Hz (auto) |
| Max PV Input Power | 7–10kW (depending on model; 1.5x over-paneling common) |
| MPPT Voltage Range | 80–500V DC or similar |
| Max Solar Charge Current | High (e.g., 100–120A MPPT) |
| Max AC Charge Current | 60–80A (from grid/generator) |
| Max Total Charge Current | 100–190A (combined) |
| Efficiency | Peak >93–95% |
| Transfer Time | <10–20ms (UPS mode) |
| Noise Level | Silent/low (<30–35 dB) |
| IP Rating | IP65 or high (water/dust resistant in similar models) |
| Operating Temperature | Wide range (suitable for tropical/coastal) |
| Communication | WiFi/app optional |
| Warranty | 5–10 years (seller-dependent) |
